What size is a HE351 Turbo?
Matthew Perez
Updated on March 09, 2026
What size is a HE351 Turbo?
Turbo Lab America HE351CW 67mm Compressor Housing and Billet Wheel.
How big is a HY35 Turbo?
60 mm is the inducer on the comp wheel, the exducer is 80 mm.
What size is a WH1C Turbo?
WH1C (56/60/12WD) The WH1C is found on 94 and some 95 Cummins, it is basically identical to the HX35 except it has a V-Band Compressor housing. The Turbine housing is a 12CM housing, is divided and has an internal wastegate.
How many MM is a HX40 Turbo?
Details about Holset Turbo HX40 62.35mm Billet Compressor Wheel + Housing.
What size is a stock HX35?
94-98 HX35’s are 8blade compressor 54mm x 83mm, turbine 58mm, 12cm^2 dual volute wastegated housing.
What MM is a stock 5.9 turbo?
Stock turbochargers usually have large exhaust housings, large-diameter turbine wheels, and smaller compressor-side inducers. For instance, an HX35 turbo from a 5.9L Cummins measures somewhere around 54/69/14, which means it has a 54mm-inducer compressor wheel, a 69mm-inducer turbine wheel, and a 14cm2 exhaust housing.
How big is a Holset HX35 turbo?
Holset HX35 Turbochargers
| Holset HX35 Turbocharger Specs | |
|---|---|
| DIMENSIONS: | |
| Length (mm) | 224 |
| Width (mm) | 250 |
| Height (mm) | 169 |
How much boost does a HX35 make?
The turbo is inefficient over 35psi boost to the point where you create excessive back pressure in the exhaust housing. From Dodgeram.org: “The HX-35 and HY-35 turbochargers are rated for a maximum boost of 44 PSI. To safely reach 44 PSI, the turbine housing MUST be sized to keep the choke point above 40 PSI.
How big is a holset h1c?
This turbo I term the big h1c because it has a 54mm compressor inducer and same exducer than the 8blade hx35/Wh1c. The other h1c is the small h1c found on the NON-intercooled cummins pickups. This has a 50mm inducer but only 7blades and has no webbing for MWE.
How many MM is a Holset HX40?
Holset HX40 Turbochargers
| Holset HX40 Turbocharger Specs | |
|---|---|
| For Engine Capacity (liters) | Up to 12 |
| Length (mm) | 231 |
| Width (mm) | 250 |
| Height (mm) | 169 |
What is the difference between HX35 and HX40?
The HX35 and HX40 share a few of the same parts but differ in the size and weight of the turbine and compressor wheels, which is why there’s a lag issue with the HX40 if there’s not quite a bit of extra fuel added. There’s been shaft breakage reported but some folks spin’em up good with no damage.
How much HP can a HX35 support?
HX35 super comes with a #8 turbine and is water cooled. It suits 1.6 to 2 liter engines reacing powers from 300 to 450 hp. The turbine is relatively small, so this turbo will actually be very streetable while still offering great power outputs.
Is the he351 and he351cw the same?
This Is the same Turbine Housing and Turbine Wheel, that we use in all of Our Upgrades for the HE351, HE351CW, and HE341. This Turbine Housing and Wheel Upgrade Is an Excellent Bolt on Upgrade for the HE351 and HE351CW Because the HE351 already has a 60 x 86 HX40 Compressor Wheel.
What is a he351 Cummins?
The HE351 is found on 04.5-07 5.9L 24 Valve Cummins. The Turbine wheel has the newer ‘ curved blade ‘ design, they flow better, but don’t spool quite as fast. The Turbine housing is a 9CM housing, is undivided and has an internal wastegate. This is from Borg Warner’s Website.
What size is the he341 compression housing?
The Turbine housing is a 9CM housing, is undivided and has an internal wastegate. The HE341 is found on ’03-04 24 Valve Cummins. Most HE341 Compressors are a 7 Blade 56 / 76.5 wheel.
Are Holset turbos proven?
Holset turbos are proven as they are the turbo on Cummins and an incredible value. Currently I run a Holset HX40 Super pushing 40 PSI. When it kicks in it is awesome but the lag is horrible – bigger is not always better for turbos! I would NOT run a knock off turbo that hard without a turbo blanket and expect serious damage if it grenades!
